EN54 COMPLIANCE STATEMENT
This fire alarm panel is fully compliant with the requirements of EN54 Part 2 (Fire detection
and fire alarm systems, control and indicating equipment) and EN54 Part 4 (Fire detection
and fire alarm systems, power supply equipment) and is certified as meeting these standards
by the Loss Prevention Certification Board (LPCB) - unless stated.
Please note, some of the engineering functions provided on the panel go
beyond the scope of EN54 Part 2. A caution symbol (left) is used to indicate
where such a function is non-compliant with EN54-2.
DO NOT affix the LPCB approval label (supplied) to the front of the panel if it
has been configured to operate in a way that would make it non-compliant
with the requirements of EN54-2.
BASIC OVERVIEW & KEY FEATURES
The fire alarm panel is designed for use with fire and security systems and includes the following features:
■• Two, four or eight detector circuits (dependent on the model purchased);
■• Four conventional sounder circuits;
• A flush or surface mountable plastic lid and enclosure;
• A wide range of secure user functions (as detailed in the separate User Manual/Log Book) including the
ability to disable/enable a large number of system functions, as specified in EN54;
• Keypad and keyswitch entry to access authorised user controls (access level two);
• A wide range of engineering functions, including:
Selectable zone delay facility
Non-latching zones facility. Note: This function is non-compliant with EN54-2.
Coincidence (double-knock) facility. Note: This function is non-compliant with EN54-2.
Zone test facility
Programming silenced sounders to resound, or not resound, when new zone in alarm
Comprehensive fault diagnostic facilities
■• The following optional EN54 Part 2 features:
Output(s) to fire alarm devices {Clause 7.8}. Four conventional sounder circuits are provided to drive
external alarm sounders.
Delays to outputs {Clause 7.11}. A delay facility (selectable on a zone by zone basis) is provided to delay
the alarm sounders, remote fire and/or auxiliary outputs.
Test condition {Clause 10.0}. A zone test facility is provided.
• The following features that are not required by EN54 Part 2:
Reset output (RESET) open collector output which provides a signal to reset any part of the fire alarm
system (if required) whilst the panel is being reset.
Remote output (REM) open collector output and Auxiliary fire relay output (AUX) which provide a signal
to any part of the fire alarm system that needs to be activated during a fire alarm condition.
Two (non-latching) auxiliary input connections; ‘class change’ and ‘alert’.
• A Fault relay output (FAULT).
• System Expansion:
If required, the CFP panel can have up to eight CFP Repeater panels connected to it. Each Repeater
panel repeats the indicators of the Main panel and allows the user entry to all Access Level 1 and 2
functions from remote parts of a site.
Communication with the Main panel is achieved using CFP761 Network Driver Cards (one required per
Repeater panel and one at the Main panel), communicating over screened 2-core, fire-resistant cable of up
to 1km in length. Contact your Supplier for details.
INSTALLATION & MAINTENANCE MANUAL • Approved Document No. DFU7004010 Rev 3 • Page 3 of 24
