Cadillac 2017 XT5 User Manual

Cadillac XT5 Owner Manual (GMNA-Localizing-MidEast-10260744) - 2017 -
crc - 1/14/16
Vehicle Care 275
Fuses Usage
F64 Engine control
module – even
F65 Engine control
module powertrain 1
F66 Engine control
module powertrain 2
F67 Powertrain TRCM
F68 –
F69 –
F70 –
F71 –
F72 –
F73 –
F74 –
F75 –
F76 –
F77 –
K1 Starter 1
K2 Run/Crank
K3 Starter 3
Fuses Usage
K4 LED/Automatic
headlamps (if
equipped)
K5 –
K6 Coolant pump
K7 Engine control
module
K8 A/C
K9 –
K10 Starter 2
Instrument Panel Fuse
Block
The instrument panel fuse block is
in the center console between the
driver and passenger seats. To
access the fuses, open the fuse
panel door, or remove the panel
from the passenger side by pulling
it out.
To reinstall the door, push the door
back into its original location.
The vehicle may not be equipped
with all of the fuses, relays, and
features shown.
