Introduction 3
M : Shown when the owner
manual has additional instructions
or information.
* : Shown when the service
manual has additional instructions
or information.
0 : Shown when there is more
information on another page —
“see page.”
Vehicle Symbol Chart
Here are some additional symbols
that may be found on the vehicle
and what they mean. For more
information on the symbol, refer to
the Index.
9 : Airbag Readiness Light
# : Air Conditioning
G : Air Conditioning Refrigerant Oil
! : Antilock Brake System (ABS)
g : Audio Steering Wheel Controls
or OnStar
®
(if equipped)
$ : Brake System Warning Light
I : Certified Technician
" : Charging System
I : Cruise Control
` : Do Not Puncture
^ : Do Not Service
B : Engine Coolant Temperature
O : Exterior Lamps
_ : Flame/Fire Prohibited
H : Flammable
. : Fuel Gauge
+ : Fuses
3 : Headlamp High/Low-Beam
Changer
( : Heated Steering Wheel
j : LATCH System Child Restraints
* : Malfunction Indicator Lamp
: : Oil Pressure
O : Power
/ : Remote Vehicle Start
> : Safety Belt Reminders
h : Start/Stop
7 : Tire Pressure Monitor
d : Traction Control/StabiliTrak
®
a : Under Pressure
M : Windshield Washer Fluid
