Black plate (55,1)
Cadillac SRX Navigation System (Include Mex) - 2012
Infotainment System 55
When this symbol is selected, the
distance and time remaining from
the current vehicle position to the
first waypoint displays.
This menu displays if the symbol
and waypoints are entered. Select
the main map view to display the
distance and time remaining from
the current vehicle position to any of
the set waypoints or final
destination.
Save: Saves a specific location to
the Address Book.
Show POI
Select to view POI information
nearby and on route.
There are several Preset options on
the bottom of the screen.
Edit: Press to display a list of POI
icons.
1. Select the POI icon to edit. The
POI icon is replaced by another
icon that is selected from the
next menu.
