Server-Based System Setup Guide
18
5.3.2 Select the appropriate video cable or adapter you need for connecting the
simulator to CAE DCU’s frame grabber:
NOTE: The CAE DCU’s frame grabber has a DVI input.
a. Use a VGA to DVI video cable to capture signals from non-CAE simulators with
VGA output.
b. Use a DVI to DVI video cable to capture signals from non-CAE simulators with
DVI output.
c. Use an HDMI to DVI adapter capture signals from non-CAE simulators with HDMI
output. Plug the adapter to a DVI cable.
5.3.3 Run the appropriate video cable to the input of the frame grabber and the
output of the simulator and connect them.
5.3.4 You need to locate the DCU on the Cameras tab and add it to a room on the
Rooms tab.
