Cafe CDD420P2TS1 - Hose and Cord Distance from Chassis

11
LEFT HAND SIDE RIGHT HAND SIDE
Drain hoses - 78 1/2” (2000mm)
Drain hoses - 70 1/2” (1800mm)
Inlet hose - 64 3/4” (1650mm)
Inlet hose - 49” (1250mm)
Power cord (excl.plug) - 29 1/2” (750mm)
Power cord (excl.plug) - 27 1/2” (700mm)
Installation Preparation
MAXIMUM DISTANCE OF HOSES AND CORD FROM CHASSIS EDGE
