49-2001030 Rev. 2 27
Removable Warming Drawer
NOTE: For models with an electric warming drawer,
before performing any adjustments, cleaning or
service, disconnect the range electrical power supply
at the household distribution panel by removing the
fuse or switching off the circuit breaker. Make sure
the warming drawer heating element is cool.
Most cleaning can be done with the drawer in place.
However, the drawer may be removed if further cleaning
is needed. Use soap and warm water to thoroughly clean.
To remove the drawer:
1. Pull drawer straight out
until it stops.
2. Press the left rail
release up and press
the right rail release
down, while pulling the
drawer forward and free.
To replace the drawer:
1. Place the left drawer rail around the inner left rail
guide and slide it in slightly to hook it.
2. Place the right drawer rail around the inner right rail
guide and slide it in slightly to hook it.
3. Slide the drawer all the way in.
Drawer
CARE AND CLEANING: Drawer
