26
6
5
Fig. 22
Fig. 20
Fig. 21
Emptying the drip tray
Pull the drip tray out of the machine and empty it. Wash and
dry the tray (6) and the grid (5) before replacing them in
their housing. (Fig. 20)
After cleaning the tray, replace it with the grid in the
machine. (Fig. 21)
Changing the side panels of the machine
For esthetic reasons you may want to change the side panels
of the machine:
• Pull the plug.
• Remove the water tank and lie the machine on one side
on a flat surface.
• Remove the bottom frame from the side and slide the panel
out of its housing.
• Replace the panel, inserting the new one in the housing
all the way and closing it with the frame matching the slots
on the machine; push the panel all the way into its housing
so that the closing tabs lock on it.
• Proceed as described above for the other side of the
machine. (Fig. 22)
