Cafina alpha - Page 31

Cafi na ALPHA – 04/2006
29
16 Technical specifi cations and installation diagram
Type of machine ALPHA -12M-1G ALPHA -12M-2G ALPHA -12CM-1G ALPHA -12CM-2G
Number of piston units 1111
Hot water service 1111
Steam service
none none 1 1
Grinders 1212
Milk yes yes yes yes
Number of beverages
Number of cups served per hour:
Coffee cream 200 200 200 200
Espresso 250 250 250 250
Cappuccino 200 200 200 200
Hot water
40 litres/hour,
175 tea servings,
each 200 ml
40 litres/hour,
175 tea servings,
each 200 ml
40 litres/hour,
175 tea servings,
each 200 ml
40 litres/hour,
175 tea servings,
each 200 ml
Maximum servings per
annum
100 000 cups 100 000 cups 100 000 cups 100 000 cups
Nominal rating 6.8 kW 6.8 kW 6.8 kW 6.8 kW
Power supply 400 V, 16 A 400 V, 16 A 400 V, 16 A 400 V, 16 A
Noise level 51 dB(A) 51 dB(A) 51 dB(A) 51 dB(A)
Ambient temperature
min. 5° C,
max. 30° C
min. 5° C,
max. 30° C
min. 5° C,
max. 30° C
min. 5° C,
max. 30° C
Relative humidity max. 80 % max. 80 % max. 80 % max. 80 %
External dimensions:
Width 50 cm 50 cm 50 cm 50 cm
Height 70 cm 70 cm 70 cm 70 cm
Depth 62.5 cm 62.5 cm 62.5 cm 62.5 cm
Dry weight 71.2 kg 76.7 kg 71.2 kg 76.7 kg
