Cafina alpha - 16 Technical Specifi Cations and Installation Diagram

Cafi na ALPHA – 04/2006
28
16 Technical specifi cations and installation diagram
Type of machine ALPHA -1W-1G ALPHA -1W-2G ALPHA -12C-1G ALPHA -12C-2G
Number of piston units 1 1 1 1
Hot water service
1 1 1 1
Steam service none none 1 1
Grinders 1 2 1 2
Milk none none none none
Number of beverages
Number of cups served per hour:
Coffee cream 200 200 200 200
Espresso 250 250 250 250
Cappuccino 0 0 0 0
Hot water
30 litres/hour,
125 tea servings,
each 200 ml
30 litres/hour,
125 tea servings,
each 200 ml
40 litres/hour,
175 tea servings,
each 200 ml
40 litres/hour,
175 tea servings,
each 200 ml
Maximum servings per
annum
100 000 cups 100 000 cups 100 000 cups 100 000 cups
Nominal rating 2.8 kW 2.8 kW 6.8 kW 6.8 kW
Power supply 230 V, 16A 230 V, 16A 400 V, 16 A 400 V, 16 A
Noise level 51 dB(A) 51 dB(A) 51 dB(A) 51 dB(A)
Ambient temperature
min. 5° C,
max. 30° C
min. 5° C,
max. 30° C
min. 5° C,
max. 30° C
min. 5° C,
max. 30° C
Relative humidity max. 80 % max. 80 % max. 80 % max. 80 %
External dimensions:
Width 50 cm 50 cm 50 cm 50 cm
Height 70 cm 70 cm 70 cm 70 cm
Depth 62.5 cm 62.5 cm 62.5 cm 62.5 cm
Dry weight 65.2 kg 70.7 kg 71.2 kg 76.7 kg
