Cafina alpha - Installation Diagram for the Cafi Na Alpha with Optional Container Ejection

Cafi na ALPHA – 04/2006
31
16 Technical specifi cations and installation diagram
16.1 Installation diagram for the Cafi na ALPHA with optional container ejection
MIN 
MIN 



















O
Description Type of machine
1 Ideal drop-in height: above bean container 180 mm all ALPHA coffee machines
2 Plug and socket 3N 400 volts 16 amps A
LPHA-12C, ALPHA-12M, ALPHA-12CM
Plug and socket 1N 230 volts 16 amps A
LPHA-1W
3 Run-off tube for coffee-machine outlet all ALPHA coffee machines
4 120 mm diameter for inlets and outlets all A
LPHA coffee machines
5 150 mm diameter for optional container ejection on all appliances with the optional container
ejection system
6 Main valve for untreated water all ALPHA coffee machines
7 Feed G
3
/8" 0.4 MPa (4 bar) all ALPHA coffee machines
8 Descaling appliance (Aqua Quell Purity) all ALPHA coffee machines
