CAL Controls CAL 3300 User Manual

Dual Relay and Dual SSd output options are factory set.
Note: (when in initial configuration only)Hold ✱ and ▲ or ▼ for 10 seconds to move
to or from output devices in shaded portion.
SP2 OPERATING MODES (see page 6)
Function Options
[Factory settings] shown in brackets
SP2.A [nonE] dV.hi dV.Lo bAnd FS.hi FS.Lo Cool
Main SP2 operating mode
SP2.b [nonE] LtCh hoLd nLin
Subsidiary SP2 mode: latch/sequence
Non-linear cool proportional band
INPUT SELECTION AND RANGING
dI.SP [1] 0.1
Select display resolution: for display of process temperature, setpoint, OFSt, Set.2, hi.SC,
LoSC
.
hi.SC sensor minimum [sensor maximum]
°C/°F
Set full scale
Lo.SC [sensor minimum] sensor maximum
°C/ºF
Set scale minimum (default 0°C or 32°F)
inPt Select input sensor [nonE]
(See SENSOR SELECTION table, page 11)
unit [nonE] °C °F bAr Psi Ph rh SEt
Select °C/°F or process units
LEVEL 3
OUTPUT CONFIGURATION
Note: ‘Read only’ after initial configuration. rSET ALL full reset to factory settings required
to change
SP1.d subsequently.
SP1.d [nonE] rLY SSd rLY1 rLY2 SSd1
Select SP1 output device
SP2.d [nonE] SSd rLY rLY2 rLY1 SSd2
Read SP2 output device
(read only)
burn Sensor burn-out/break protection
Caution: Settings affect fail safe state.
SP1 SP2
[uP.SC] Upscale Upscale
dn.SC Downscale Downscale
1u.2d Upscale Downscale
1d.2u Downscale Upscale
rEu.d Select output modes: Direct/Reverse
Caution: Settings affect fail safe state.
SP1 SP2
[1r.2d] Reverse Direct
1d.2d Direct Direct
1r.2r Reverse Reverse
1d.2r Direct Reverse
Select Reverse on SP1 for heating and Direct for
cooling applications.
rEu.L Select SP1/2 LED indicator modes
SP1 SP2
[1n.2n] Normal Normal
1i.2n Invert Normal
1n.2i Normal Invert
1i.2i Invert Invert
SPAn [0.0] to ±25% sensor maximum
Sensor span adjust
For recalibrating to align readings with another instrument e.g. External Meter, data logger.
See Full Operating Manual (ADVANCED SETTINGS).
ZEro [0.0] to ±25% sensor f/s
Zero sensor error (see Sensor span adjust above).
ChEK [oFF] on
Select control accuracy monitor
rEAD [Var] hi Lo
Read control accuracy monitor
tECh [Ct A] CT b Ct 1 Ct 2 Ct 3 Ct 4 oS 1 uS oS 2
Read Autotune tuning cycle data (see Operating Manual)
UEr Software version number
rSET [nonE] ALL
Resets all functions to factory settings
Caution: This selection will lose all of the current settings.
8
English
LEVL 3
