Cal-Royal CRCODE-202 - Outside Lock Installation

&KHFNWKDWWKHODWFKLVFRUUHFWO\¿WWHGDVVKRZQRQ
right image.
Outside Lock Installation
1. Place Outside Lock on door.
2. Align hub onto the spindle and 4
screw posts through prep doors.
3. Align the mounting plate of the Inside
lock and fasten with 4 screws.
