CalDigit Thunderbolt 3 mini Dock - Supported Resolutions for Dual Monitors; Ethernet and USB Ports

7
Supported Resolutions for Dual Monitors
Ethernet
USB
The Thunderbolt™ 3 mini Docks have a single Gigabit Ethernet port to connect to a Gigabit Ethernet
network. Your computer will connect to whichever network is connected to the Thunderbolt™
3 mini Dock by default. These settings can be changed in the “Network” section under “System
Preferences”. The Ethernet port also supports wake-on-LAN which allows your computer to wake
from standby remotely via the network.
The Thunderbolt™ 3 mini Docks USB ports support the following performance levels.
Resolution Video Display Frequency Dual Monitor
2K (2560 x 1600) 60 Hz Yes
Full HD (1920 x 1080p) 60 Hz Yes
4K 60 Hz Yes
2K (2560 x 1600) 30 Hz Yes
Full HD (1920 x 1080p) 30 Hz Yes
Thunderbolt™ 3
mini Dock Dual HDMI
Thunderbolt™ 3
mini Dock Dual DisplayPort
No. USB Ports 2 1
USB
USB 3.0 (5Gb/s)
USB 2.0 (480Mb/s)
USB 3.0 (5Gb/s)
