1 Introduction
The CAMAG Derivatizer is an automated spraying device which sets a new standard of
reproducibility in the reagent transfer onto TLC plates by employing a unique "micro
droplet" spraying technology. The CAMAG Derivatizer ensures homogeneous and
reproducible application of all common reagents. Moreover, the CAMAG Derivatizer
offers further advantages compared to manual spraying:
• Environmentally friendly and safe handling through a closed system
• Intuitive handling and easy cleaning
• Low reagent consumption through efficient operation (4 mL for 20 x 20 cm plates
and 2 – 3 mL for 20 x 10 cm plates)
• Reproducible and user-independent results
1.1 Precaution
• Please read this operating manual before starting the installation! This manual
contains information and warnings the user has to follow to ensure reliable
operation of the instrument
• If the instrument is used in a manner not specified in this manual, the protection
provided by the equipment may be impaired
• Some interior parts of the instrument are under AC power. Careless and improper
use can cause injury. Unauthorized manipulations can cause damage
• This sign indicates (on instrument and in this manual) that failure to take note of
the accompanying information may result in damage to the instrument
• The instrument is manufactured and tested in accordance with the respective
European safety publications shown on the Declaration of Conformity (DoC). The
instrument complies with safety class 1 and has been designed for indoor use only
(IP 20). Further, this device has passed the CAMAG Quality Assurance tests and
has been delivered in safe operation condition. For detailed instrument data see
chapter ”Technical data”
• Attention: For safety reasons the instrument may only be used for the purposes
described in the operating manual
• To avoid injury use adequate safety equipment (protective goggles, gloves etc. if
applicable) when working with the instrument
• Before first operation, check whether the voltage shown on the instrument
matches your local mains voltage. The power cord may only be connected to a
grounded, fused (not higher than 16 A) outlet. Do not use extension cords
without ground contact
