Chapter 2: System Hardware
71
ePMP 4500 Access Point mounting bracket
The ePMP 4500 AP module is designed to be mounted with a sector antenna or pole-mounted using the
mounting bracket provided in the box with the radio.
An overview of ePMP 4500 AP mounting bracket is shown in Figure 35
Figure 35: ePMP 4500 Access Point module mounting bracket
ePMP 4500 Access Point interfaces
The Ethernet port is located at the bottom of the unit. This interface is described in Table 22.
Table 22 ePMP 4500 Series – rear interfaces
Port
name
Connector
Interface
Description
Eth
RJ45
PoE input
Power over Ethernet (PoE).
Note
All RJ45 Ethernet LAN cables used for
providing power or are connected to
power ports (PoE) must be UL
certified with VW-1 markings.
100/1000BASE-T Ethernet
Data
SFP
SFP
Optical or Copper Gigabit
Ethernet
Management and/or data
ePMP 4500 Access Point specifications
The ePMP 4500 connectorized module conforms to the specifications listed in Table 23 and Table 24.
