Cambridge Audio 840A - Power Amplifier Right PCB BOM

AP16376/7
setoNtnedItnenopmoCytQepyT/noitpircseDeulaVoNPA
RESISTORS
910R 0.125 W Metal Film 1 R70
2K2 0.125 W Metal Film 1 R80
4K7 0.125 W Metal Film 5 R36 , R66, R68, R72, R74,
10K 0.125 W Metal Film 6 R16, R69, R75, R76, R77, R85,
22K 0.125 W Metal Film 1 R48
33K 0.125 W Metal Film 1 R81
47K 0.125 W Metal Film 2 R43, R90,
100K 0.125 W Metal Film 1 R96
1M 0.125 W Metal Film 1 R71
10R 0.25 W Metal Film 2 R1, R32
18R 0.25 W Metal Film 1 R12
56R 0.25 W Metal Film 1 R9
68R 0.25 W Metal Film 3 R3, R6, R7
100R 0.25 W Metal Film 9 R2, R4-R5, R14, R17, R18, R23, R24,
150R 0.25 W Metal Film 1 R62
470R 0.25 W Metal Film 3 R30, R58, R59
1K 0.25 W Metal Film 6 R52-R53, R63, R80, R99, R101
1K1 0.25 W Metal Film 2 R60, R61
1K2 0.25 W Metal Film 1 R11,
1K8 0.25 W Metal Film 1 R10,
2K2 0.25 W Metal Film 4 R8, R13, R27, R56,
2K7 0.25 W Metal Film 2 R93, R94
3K3 0.25 W Metal Film 1 R34
3K6 0.25 W Metal Film 1 R33
4K7 0.25 W Metal Film 3 R42, R46, R82
10K 0.25 W Metal Film 8
R39, R50, R51, R64, R73, R83, R84, ,
R89,
16K 0.25 W Metal Film 3 R49, R54, R55
22K 0.25 W Metal Film 5 R15, R57, R67, R81, R100
47K 0.25 W Metal Film 8
R35, R38, R44, R45, R47, R65, R66,
R86
56K 0.25 W Metal Film 1 R92
75K 0.25 W Metal Film 1 R91
100K 0.25 W Metal Film 4 R37, , R97, R98
S88R1mliFlateMW1R33 pace o PCB
S14R1nobraCW1R074 pace o PCB
0R1 3 W Wire Wound 6 R19-R22, R25, R26 S pace o PCB
S
13R1dnuoWeriWW35R1 pace o PCB
2R2 3 W Wire Wound 1 R28
Inductor damping res.
No need to stand o PCB
10R 3 W Wire Wound 1 R29
220R 3 W Carbon 1 R40
CAPACITORS
100pF
Ceramic 100V 10% Pitch=
3mm
1 C10, C39
10nF X1 CAP
MEX103K300A02 Pitch
=10mm
3 C11, C12, C20
100nF
Ceramic 100V 10% Pitch=
5mm
2 C18, C21
100nF Polyester Pitch= 10mm 1 C2
10uF
16V Electrolytic Radial Non
Polarised (6.4mm) Pitch=
5mm
2 C20, C38
10uF
63V Electrolytic Radial
(5mm diam) Pitch= 3.5mm
1 C40
22uF
50V Non Polarised
Electrolytic Radial (5.2mm)
Pitch= 2.5mm
1C3
Cambridge Audio Azur 840A Amplier Power Amp Right PCB BOM
