Cambridge Audio 840A - Power Amplifier Left PCB BOM

AP16696/9
setoNtnedItnenopmoCytQepyT/noitpircseDeulaVoNPA
RESISTORS
10R 0.125 W Metal Film 1 R87
100R 0.125 W Metal Film 3 R86, R90, R91
910R 0.125 W Metal Film 1 R70
4K7 0.125 W Metal Film 6 R36, R42, R46, R68, R75, R89
10K 0.125 W Metal Film 3 R69, R83, R85
22K 0.125 W Metal Film 1 R48,
47K 0.125 W Metal Film 4 R43, R44, R45, R50
100K 0.125 W Metal Film 2 R37, R88
1M 0.125 W Metal Film 1 R71
10R 0.25 W Metal Film 2 R1, R32,
18R 0.25 W Metal Film 1 R12
56R 0.25 W Metal Film 1 R9
68R 0.25 W Metal Film 3 R3, R6, R7
100R 0.25 W Metal Film 10
R2, R4, R5, R14, R17, R18, R23,
R24,
150R 0.25 W Metal Film 1 R62
470R 0.25 W Metal Film 3 R30, R58, R59
1K 0.25 W Metal Film 4 R52, R53, R63, R80,
1K1 0.25 W Metal Film 2 R60, R61
1K2 0.25 W Metal Film 1 R11,
1K8 0.25 W Metal Film 1 R10
2K2 0.25 W Metal Film 4 R8, R13, R27, R56
2K7 0.25 W Metal Film 2 R74, R76
3K3 0.25 W Metal Film 1 R34
3K6 0.25 W Metal Film 1 R33
10K 0.25 W Metal Film 4 R16, R51, R64, R66,
16K 0.25 W Metal Film 3 R49, R54, R55
22K 0.25 W Metal Film 4 R15, R57, R67, R81
47K 0.25 W Metal Film 5 R35, R47, R65, R73, R82
56K 0.25 W Metal Film 1 R73
75K 0.25 W Metal Film 1 R72
100K 0.25 W Metal Film 2 R78, R79,
BCPffoecapS83R1mliFlateMW1R33
BCPffoecapS14R1mm
81=hctiPnobraCW1R074
0R1 3 W Wire Wound 6 R19-R22, R25, R26 Space o PCB
BCPffoecapS13R1dnuoWeriWW35R1
2R2 3 W Wire Wound 1 R28
Inductor damping res.
No need to stand o PCB
BCPffoecapS.SERLEBOZ92R1dnuoWeriWW3R01
BCPffoecap
S04R1mm5.22=hctiPnobraCW3R022
CAPACITORS
100pF
Ceramic 100V 10% Pitch=
3mm
2 C10, C14
100nF
Ceramic 100V 10% Pitch=
5mm
1 C18
100nF Polyester 10% Pitch= 10mm 1 C2
10uF
16V Non Polarised Electrolytic
Radial (5.2mm) Pitch=
2.5mm
1 C20
22uF
50V Non Polarised Electrolytic
Radial (5.2mm) Pitch=
2.5mm
1C3
Cambridge Audio Azur 840A Amplier Power Amp Left PCB BOM
Note: resistors, capacitors and other 'generic' electronic components are not usually stocked
by the manufacturer. Please obtain these locally.
37
