Cambridge Audio 840A - Rectifier PCB; Rectifier PCB Schematics

Cambridge Audio Azur 840A Amplifier
AP17575/2 Rectifier PCB Schematic
F1
T6A3 AL
LVD!
F2
T6A3 AL
LVD!
J1
TERMINAL
J2
TERMINAL
J3
TERMINAL
YELLOW
ORANGE
RED
C1
10nF
C2
10nF
C3
10nF
J4
TERMINAL
J5
TERMINAL
+48V OUT
-48V OUT
J6
TERMINAL
GREEN
RED
ORANGE
YELLOW
BROWN
BLUE
1
2
3
1
2
36 V
36 V
0V
115 DEG C
Primary
Secondary
230 V
0V
GREEN
4 38 V
5.5A
5.5A
100 mA
RED
ORANGE
YELLOW
1
2
3
36 V
36 V
0V
Secondary
GREEN
4 38 V
5.5A
5.5A
100 mA
MAIN TRANSFORMER
TO POWER AMP SUPPLY RIGHT
VIOLET
BLUE
3 1
4 2
BR1
BRIDGE BR-254
To enhance viewing, please print to A3 44
