1 In systems designed to accommodate this signal, during a call from an entry panel, the LED lit permanently indicates
that the door is open.
2 The function may also be available with communication is not activated, where the system permits it.
Standard functions
Answering a call
Answering a call
Communication active
Entry panel door release displayed
Ending communication
Adjusting the ring (high-medium-o) (red LED)
Activating/deactivating communication (blue LED)
Door lock release
1
(blue LED)
1 Intercom 1/3 (blue LED)
2 Intercom 2/4 (blue LED)
Auxiliary 1 (blue LED)
Auxiliary 2/Porter call (blue LED)
2
Activation of communication a, opening of the door of the selected entry panel b and activation of the auxiliary
controls c d.
Functions available during a call
