CAME AGT V User Manual

Page 8 - Manual FA01620-EN - 08/2022 - © CAME S.p.A. - The contents of this manual may be changed at any time and without notice. - Translation of the original instructions
Example set-up with VA/01
The option to switch on 4 monitors at the same time is only available for systems with VA/01.
Lb
La
VA/01
L1 L2 L3
N° Slave
N° Master
Cable length
Section Cable type
La, Lb VCM/1D or UTP CAT5
L1, L2, L3 VCM/2D
Section Max. section length (m)
La + Lb 100 VCM/1D or 60 UTP/CAT 5
L1 + L2 + L3 300
La + Lb + L1 (L2, L3) 150
La + Lb + L1 + L2 + L3 600
Maximum number of internal receivers per cable type
VCM/1D
Master 4321
Slave 4567
UTP CAT5
Master 321
Slave 067
