Only for the AF43S / AF43SM radi-fre-
quency cards.
- position jumper as shown depending on
the series of transmitters you are using.
7 Activating the radio control
Connect the antenna’s RG58 cable.
Cut off the main power supply, and remove any batteries.
Fit the AF board onto the electronic board.
The electronic board recognizes the AF board only when the operator is powered up again.
Keep the CH1 button on the electronic board pressed: the warning LED flashes.
Press any button on the transmitter to send the code: the LED will stay on to let you know that the code has been stored. Repeat /
for any other transmitter buttons.
