Page 3 - Manual FA01734-EN - 06/2022 - © CAME S.p.A. - The contents of this manual may be changed, at any time, and without notice. - Translation of the original instructions
LEGEND OF SYMBOLS
This symbol tells you to read the part very carefully.
This symbol tells of parts that have to do with safety.
This symbol tells what to say to the user.
INTENDED USE AND LIMITS TO USE
Intended use
The CBX series gearmotor was designed to mainly power sectional doors which are directly coupled onto Ø 1” (Ø 25,4 mm) spring loaded,
chain transmission shafts. It is also suited for large sliding and folding doors with their relative accessories.
Any use other than the above mentioned intended one and installations made differently than what is explained in this technical manual,
are prohibited.
Limits to use
For large, directly-coupled
sectional doors
• door height up to 5.5 m
• Speed* 7.15 m/1’ with ~Ø 105 mm reel barrel
• Speed* 9.3 m/1’ with ~Ø 138 mm reel barrel
For large chain-transmission
sectional doors
• door height up to 8.5 m
• Speed* 9.15 m/1’ with ~Ø 208 mm reel barrel
For large, sliding or folding doors • Door width of up to 5.5 m for the C-BXE / C-BXE24 / C-BXET / C-BXEK
• Door width of up to 11 m for C-BX / C-BXT / C-BXK
• Door weight max 1,000 kg
* Speed is variable depending on the barrel diameter. The descriptions are based on common cable winch barrels, in the above mentioned
sizes, as used by mainstream sectional door manufacturers.
Contexts of operation
C-BX / C-BXK / C-BXE / C-BXEK Residential - Apartment block - Industrial
C-BXE24 Residential - Apartment block
C-BXT / C-BXET Industrial
