2
v
#!-%
2
v
C-BX / C-BXE
C-BXT / C-BXET
C-BXE24
C-BXK / C-BXEK
Page 5 - Manual FA01734-EN - 06/2022 - © CAME S.p.A. - The contents of this manual may be changed, at any time, and without notice. - Translation of the original instructions
Technical information
C-BX C-BXK C-BXE C-BXEK C-BXT C-BXET C-BXE24
Power to motor
230V A.C.
50/60Hz
230-400V A.C.
50/60Hz
24V D.C.
50/60Hz
Draw* A 2.2 3.6 2.2 3.6 2.5 9
Power* W 450 750 450 750 780 240
Max torque* Nm 60 120 60 120 80 25
Gear ratio 1/67,45
Max n. of shaft revolutions 32 32 16 16 32 16 16
Rotation velocity rpm 21.5 2.5
Duty cycle 30% 30% 30% 30% 50% 50% intensive
Protection rating IP54
Motor’s thermal protection 150 °C /
Weight kg 11.3 11.8 13.3 13.9 11.2 11.3 11.2
Working temperature -20 / +55 °C
Operator insulation Class I
* Values depending on control panel in use
Overall dimensions
