CAME FTL Series User Manual

M1 N1 ENC1
M2 N2 ENC2
M1 N1 ENC1
M2 N2 ENC2
M2M1
M1M2
M N E
M1 N1 ENC1
M2 N2 ENC2
M N E
M1 N1 ENC1
M2 N2 ENC2
p. 17 - Manual FA00995-EN - 01/2018 - © CAME S.p.A. -
Translation of the original instructions
BROWN
BLACK
BLUE
BROWN
BLACK
BLUE
For two-leaf swing gates.
Gearmotor installed on the left and operator
installed on the right (inner view) with operator
delayed when closing.
Operator installed on the left and gearmotor
installed on the right (inner view) with operator
delayed when closing.
(Default setting)
Operator with gear motor
Operator installed on the right (inner view).
BROWN
BLACK
BLUE
For one-leaf swing gates.
BROWN
BLACK
BLUE
Operator
Operator installed on the left (outer view).
(Default setting)
