p. 22 - Manual FA00995-EN - 01/2018 - © CAME S.p.A. -
Translation of the original instructions
Pre-flashing (pre-flashing duration: 5 s)
By default, the feature is disabled.
To enable it:
select the DIP switches as shown and press the PROG key on the board. The PRG LED stays on and the
buzzer sounds off for 1 second.
To return to the default setting, press PROG again The LED blinks and the buzzer sounds off 2 times
Closing thrust
By default, the feature is disabled.
To enable it:
select the DIP switches as shown and press the PROG key on the control board. The PRG LED stays on
and the buzzer sounds off for 1 second.
To return to the default setting, press PROG again. The LED blinks and the buzzer sounds off 2 times
Saving the trimmer value
Use the trimmers to set the automatic closing time (A.C.T.), the opening and closing latching points, the
second motor's closing-delay speed, the slow-down speed (SDS) and the sensitivity (SENS.).
To save the values:
select the DIP switches as shown and press the PROG key on the control board. The PRG LED stays on
and the buzzer sounds off for 1 second.
Services test
By default, the feature is disabled.
To enable it:
Select the DIP switches as shown and press the PROG key on the control board. The LED stays on and
the buzzer sounds for 1 second.
To return to the default setting, press PROG again. The LED blinks and the buzzer sounds off 2 times
Button-activated maintained action
By default, the feature is disabled.
To enable it:
select the DIP-switches as shown and press the PROG key on the control board. The LED stays on and
the buzzer sounds for 1 second.
To return to the default setting, press PROG LED button pressed The LED blinks and the buzzer sounds
off 2 times
⚠
The gate opens and closes when the button is kept pressed.
Opening button connected on 2-3P (contact NO) and closing button connected on 2-7 (contact NO)
All other control devices, even radio-based ones, are excluded.
