CAME TH/124 - Installation Guide; Mounting Location and Preparation

A
B
C
p. 5 - Manual FB00802-EN v. 1- 07/2017 - © CAME S.p.A. - The contents of this manual may be changed, at any time, and without notice.
Installing
Remove the protective shell from
the terminal board 󱭉.
Press button ❶ and separate
the base from the body of the
device 󱭈.
Install the device in a place suitable
for detecting the room's tempera
-
ture, possibly onto an inside wall,
and avoid any nooks, behind doors,
near curtains or heat sources.
❶
