Page 5 - Manual FA01812-EN - 06/2022 - © CAME S.p.A. - The contents of this manual may be changed at any time and without notice. - Translation of the original instructions
Technical data
MODELS XVP F XVP S
IP protection rating 55 55
IK protection rating 08 08
Operating temperature (°C) -40 ÷ +50 -40 ÷ +50
Storage temperature (°C) * -25 ÷ +70 -25 ÷ +70
Current draw in standby mode (mA) 700 700
Maximum consumption without electric lock (mA) 1000 1000
Maximum consumption with electric lock (mA) 1500 1500
Power supply (V DC) 12-24 DC 12-24 DC
PoE power supply
IEEE 802.3at POE+
(25.5W)
IEEE 802.3at POE+
(25.5W)
Maximum relay current (A) 11
Relay maximum voltage (V) 30 30
Video standard H.264 H.264
Standard wireless Bluetooth LE 5.0 Bluetooth LE 5.0
Radio frequency (MHz) 2400 2400
Transmission power (dBm) 00
Proximity sensor range (cm) 30 ÷ 130 30 ÷ 130
Average life (hours)** 90.000 90.000
Size
386
127
55
XVP-F
153 50
406
XVP-S
(*) Before installing the product, keep it at room temperature where it has previously been stored or transported at a very high or very low temperature.
(**) The average product life is a purely indicative estimate. It applies to compliant usage, installation and maintenance conditions. It is also infl uenced by other factors, such as climatic and
environmental conditions.
The minimum on temperature from cold is -25°C.
If the temperature of the display glass reaches 80°C when exposed to sunlight, the device’s thermal protection is activated. Normal operation is restored only once the glass has
cooled down.
The wall must be perfectly fl at and fl ush with the bottom of the box to reach the specifi ed IP rating.
