CAME ZBX7 User Manual

-16-
COLLEGAMENTI ELETTRICI - ELECTRICAL CONNECTIONS - BRANCHEMENTS ÉLECTRIQUES
ELEKRISCHE ANSCHLÜSSE - CONEXIONES ELÉCTRICAS
W
E1
U
W
V
L1
L2
Alimentazione 230V (a.c.)
230V (a.c.) power input
Alimentation 230V (c.a.)
Stromversorgung 230V (Wechselstrom)
Alimentación 230V (a.c.)
Motore monofase 230V (a.c.)
230V (a.c.) single-phase motor
Moteur monophasé 230V (c.a.)
Einphasenmotor 230V (Wechselstrom)
Motor monofásico 230V (a.c.)
Uscita 230V (a.c.) in movimento
(es.lampeggiatore - max. 25W)
230V (a.c.) output in motion
(e.g. flashing light - max. 25W)
Sortie 230V (c.a.) en mouvement
(ex. branchement clignotant - max. 25W)
Ausgang 230V (Wechselstrom) in Bewegung
(z.B. Blinker-Anschluß - max. 25W)
Salida de 230V (a.c.) en movimento
(p.ej. lámpara intermitente - max. 25W)
Uscita 230V (a.c.) lampada ciclo - max. 60W
230V (a.c.) max.60W - cycle lamp
Sortie 230V (c.a.) lampe cycle - max. 60W
Ausgang 230V (Wechselstrom)
Betriebszyklus-Anzeigeleuchte - max.60W
Salida de 230V (a.c.) lámpara ciclo - max.60W
10 11 1 2 7 C1L1
L2
UVWE1
3P C3
FA FC F
B1
B2
E
D
UVWE1
UVWE1
2
1
34
5
6
78910
ON
