CAME ZBX7 User Manual

-5-
Other functions
- Automatic closing. The automatic
closing timer is automatically activated
at the end of the opening cycle. The
preset, adjustable automatic closing
time is automatically interrupted by the
activation of any safety system, and is
deactivated after a STOP command or
in case of power failure;
- Partial opening . Gate opening for
passage on foot is activated by
connecting to the 2-3P terminal blocks
and it can be adjusted by the AP.PARZ.
trimmer. By using this function,
automatic closure varies as follows:
1) Dip 1 ON - Automatic closure
activated.
-after a partial opening, the closure time
does depend on any adjustment of the
TCA trimmer.
2) Dip 1 OFF - Automatic closure
deactivated.
- If the TCA trimmer is set to the
minimum, after a partial opening,
automatic closure counting does not
begin;
- If the TCA trimmer is set to the
maximum, after a partial opening,
closing time is set to 8 seconds.
- "Operator present" . Gate operates only
when the pushbutton is held down (the
radio remote control system is
deactivated);
- Slowing at the limit switch .
FUNCTION AVAIABLE ONLY FOR GATES
WEIGHING
UP TO 300 KG, OTHERWISE IT
MUST BE DISACTIVATED
The gate slows down before the
opening or closing movement is
completed.
Only works with the optical reader on.
After every opening and closing of the
safety door or after restoring the
voltage, the slowing function is active
from the 2
nd
command onwards.
- Pre-flashing . After an opening or
closing command, the flasher connected
to the W-E1 flashes for 5 seconds
before beginning the procedure;
- Closing command. Function of closing
the gate only, with a wireless control
device connected to contact 2-7, set dip
1 to ON (4-way module), see page 22;
- Opening command. Function of
opening the gate only, with a wireless
control device connected to contact 2-
3P, set dip 2 to ON (4-way module), see
page 22;
-Type of command :
-Open-stop-close-stop by button and
transmitter;
-Open-close by button and transmitter;
-Open only by transmitter.
Adjiustments
- Automatic closure time;
- Partial opening time.
IMPORTANT: Shut off the mains power
before servicing the inside of the unit.
