COMPORTAMENTO LED MASTER:
STATO LED COMPORTAMENTO SIGNIFICATO
Work
(WLAN OFF)
● (red)
● (green)
Off
Blinking
(1 blink @10 Hz every 1s)
The valves island is in work status
and the WLAN module (optional) is
connection is NOT present or NOT
connected
Work
(WLAN ON)
● (red)
● (green)
Off
Blinking
(1 blink @10 Hz every 2 s)
The valves island is in work status
and the WLAN module (optional) is
present and connected
Valve alarm ● (red)
Blinking
(1 blink @10 Hz every 1 s)
At least a valve has an alarm:
- Subbase Overheating
- Solenoid Overcurrent
- Solenoid Overheating
- Solenoid Not Energized
- Solenoid Interrupted
Comunication
Alarm
● (red)
Blinking
(2 blink @10 Hz every 1 s)
The left terminal (Master) has lost
communication with the sub-bases
Under Voltage
alarm
● (red)
Blinking
(3 blink @10 Hz every 1 s)
The power supply is under the
voltage threshold.
Numbering
Alarm
● (red)
● (green)
Blinking
(1 blink @10Hz every 1s)
Off
The island is in error of numbering,
it has never been put in
communication with any sub-base
Carry out the numbering procedure
as per point 6.6
Mapping
Alarm
● (red)
● (green)
Blinking
(2 blink @10 Hz every 1 s)
Off
The island is in a mapping error.
The layout of the sub-bases has
been changed, check it and if
necessary repeat the numbering
procedure as per point 6.6
