42
33-0013 X X X X
58 Flange Gasket
33-0014 X X X X X X X X X
Electrical Components
Ref
#
Name of Part
Part ID Model Sizes
ALL 500 750 1100 1200 1500 1750 2000 2500 3000 3500 4000 4500 5000
SM005S X X X X
SM010S X X X
SM015S X X
60
Variable Frequency
Drive (1/2HP, 1HP,
1 1/2HP, 3HP)
SM23S X X X X
61 Ignition Module DF 35-67 X
62 Control BTC-2PA X
63 Control PXZ X
64 On/Off Switch W51A152A X
65 Indicator Lights IND.LGT.SET X
66 Fuse BK/AGC-4 X
67 24V/120V Relays LY1F 24/120 X
68 75VA Transformer HCT-01J28807 X
1/2 HP X X X X
1 HP X X X
1 1/2 HP X X
69 Electrical Motor
3 HP X X X X
