Part Name Part ID
Dynaforce® Models
ALL
300 350 400 500 600 800
1000 1200 1400 1600 1800 2000 2500 3000 3500 4000 4500 5000
1
Heat Exchanger
(Incl. “V” Baffles)
15-2001 X X
15-2002 X X
15-2003 X X
15-2004 X X
15-2005 X
15-2006 X X
15-2007 X
15-2008 X
15-2009 X
15-2010 X X
15-2011 X
15-2012 X
2 Wrap Assembly
90-14005 X X
90-9100-04 X X
90-15209 X X
90-14011 X X
90-14013 X
90-15209 X X
90-15210 X
90-14017 X
90-15099 X
90-2010 X X
90-2011 X
90-2012 X
5 Base Support
14-1025 X X X X X X X X X
14-1073 X X X X X X
14-1018 X X
14-1071 X X X
7
Condensate Bin
Assembly
14-1024 X X X X X X X
14-1010 X X X X X X
14-1017 X X X X X
8 Base Panel
14-5012A X X X X X X X
14-5206A X X X X X X
14-5306 X X X X X
9 Base Support Leg
14-6007A X X X X X X X
14-5207A X X X X X X
14-5307 X X X X X
10
Base Support Stiffener
Under Leg
14-6010A X X X X X X X
14-5212A X X X X X X
14-5312 X X X X X
