PART
DESCRIPTION
1
SMOKE EXTRACTOR GRID - VERTICAL CHIMNEY
2
HOB GLASS COVER
3
SIDE PANELLING REMOVABLE FOR MAINTENANCE
4
PRODUCT LABEL - SERIAL NO. - CE MARK
5
GRILL DOOR
6
HANDLE OF GLASS COVER
7
COMMANDS FRONT PANEL
8
GAS TAP - HOB BURNER
9
GAS TAP FOR GRILL
10
ELECTRONIC SWITCH-ON BUTTON
11
HANDLE FOR GRILL DOOR
12
GRILL COMPARTMENT INNER GRILL
13
GRILL COMPARTMENT INNER DRIPPING PAN
14
GAS MAIN RAMP TERMINAL
15
12V GENERATOR CONNECTION CABLES
16
EYELETS FOR COMBUSTIVE AND COOLING AIR CIRCULATION
17
STEEL SIDE FRAMES
18
GAS TAPS ADJUSTMENT KNOB
