19
Changing the fuel filter
1. The fuel filter is a spin-on Cartridge.
Remove by turning anti-clockwise when viewed from
below, see picture….
2. Replace the fuel filter cartridge every 400 hours
3. Remove metal bung and O Ring from the
old fuel filter and fit to new fuel filter (see below)
4. Apply fuel oil thinly over the filter gasket and tighten
into position – hand tight
5. Prime fuel system…
Place a rag or receptacle under the Fuel Filter
Slacken the Bleed Screw
Pump the Fuel Primer until air free fuel comes from
the Bleed Screw, then tighten the Bleed Screw
Continue to pump until a reasonable effort is
required.
6. Check for leaks
Note: Do not get fuel on the flexible engine mounts
.
Metal bung in Fuel filter, must
be transferred to new fuel filter
