31
Calorifier Connection Points – CL 38/42/52/60/70T
Calorifier connection points are as shown below. Connection stubs are provided and
are suitable to accept 15mm (5/8”) dia bore flexible hose. The hose must be secured
with suitable hose clips to give a watertight connection capable of withstanding a
water pressure of 15 psi. Hoses are not supplied by Engines Plus.
If no Calorifier is fitted, the connections must be blanked off, They MUST NOT BE
CONNECTED DIRECTLY TOGETHER, Blanking plugs are available on request.
HOT WATER OUTLET
