Candy CCE116/1X User Manual

35
4. Leave up the cooker hood and hang onto the wall bracket hook.
Cooker hook
Wall
bracket
5. Fix the one-way-valve to the air outlet of the cooker hood. Then,
attached the exhaust pipe onto the one-way-valve as shown below.
Exhaust pipe
Cooker hood
37

Candy CCE116/1X Specifications

General

Bulb type	LED
Bulb power	2 W
Number of bulbs	2 bulb(s)
Noise level	62 dB
Intensive speed	No
Number of speeds	3
Type of extraction	Ducted/Recirculating
Noise level (low speed)	56 dB
Maximum extraction power	305 m³/h
Lighting efficiency class	A
Fluid dynamic efficiency class	E
Grease filtering efficiency class	C
Motor power	- W
Connected load	1000 W
AC input voltage	220 - 240 V
AC input frequency	50/60 Hz
Energy efficiency scale	A+++ to D
Annual energy consumption	36 kWh
Type	Wall-mounted
Cord length	1.5 m
Product color	Stainless steel
Motor included	Yes
Exhaust location	Top
Exhaust connection diameter	150 mm
Number of filters	2 pc(s)
Grease filter type	-
Package depth	245 mm
Package width	650 mm
Package height	540 mm
Package weight	8850 g

Weight and Dimensions

Depth	480 mm
Width	600 mm
Height	- mm
Weight	7300 g
Height (max)	940 mm
Height (min)	573 mm
Height without chimney	180 mm
