BLM550+ Booklet Maker Service Support Guide
B. Installation Weight and Dimensions
Table 11 – Approximate Weight
Watkiss P2T 2-Knife Trimmer
Table 12 – Dimensions
Watkiss P2T 2-Knife Trimmer
38.1” 968 mm 45.0” 1,142 mm 36.4” 924 mm
C. Installation Space Requirements
The BLM550+ Booklet Maker approximate installation space requirements may
differ, depending on how the machine is configured and the optional modules
attached. Always ensure that there is enough space for service and operation
of the device. The Installation space for the BLM550+ Booklet Maker adds to
the VarioPrint 6000+ Series device installation space when configured with the
High Capacity Stacker.
IMPORTANT
• In addition to the space required by the VarioPrint6000+ Series the following
space requirements are necessary for the proper servicing of the equipment
(with all doors and access panels open).:
• The BLM550+ Booklet Maker (including the connecting bridge) requires
approximately 87.8” x 112.6” (2,230 mm x 2,860 mm) of space
• The BLM550+ Booklet Maker (including the connecting bridge),
connected with the Book Stacker requires approximately 91.3” x 129.5”
(2,320 mm x 3,290 mm) of space
• The BLM550+ Booklet Maker (including the connecting bridge),
connected with the Book Stacker and Watkiss P2T 2-Knife Trimmer
requires approximately 107” x 153.5” (2,700 mm x 3,900 mm) of space
• As indicated in Figure 1, for the proper servicing of the equipment (with all
doors and access panels open) make sure to keep the back of the
BLM550+ Booklet Maker at least 23.6” (600 mm) away from a wall and keep
the sides at least 21.7” (550 mm) away from a wall.
8 Includes the connecting bridge. The dimensions are when the Booklet Maker is assembled.
9 The height is adjustable from 34.8” (885 mm) to 38.1” (968 mm)
BLM550+ Booklet Maker Service Support Guide March 2015
Revision 1 Page 9
