BLM550+ Booklet Maker Service Support Guide
Table 15 – BLM550+ Booklet Maker Suggested Car Stock Continued
Item
Item Number
1
BEARING, DRAWN CUP 8x12x2 2
1060084221
BEARING, INNER RING 5X8 2
1060084222
NYLON, SPACER 8.1MMX11MM 2
1060084223
1 Item Numbers and Part Numbers are subject to change without notice.
Table 16 – BLM550+ Booklet Maker Suggested Spare Parts
Item
Item Number
1
ELECT ASSY, V/FCN CLUTCH
1060059270
FUSE,1.25", 7.0A,HRC-QUIC
1060059289
MOTOR, (PSQ) VALEO GEARED
1060059295
CLUTCH,(PSQ) CB4 CW 24v D
1060059320
PSQ,DELUX G8STITCH HEA RR
1060067208
KIT,(PSQ) BLADE&ANVIL RR
1060067383
STITCHHEAD MAINTENANCE KI
1060068961
G20346B SUPPORTER PIN
1060068964
ADD.ITEMS STITCHHEAD MAIN
1060068969
CLUTCH, PSQ EC75 CW 24V 1
1060096381
SPRING,EXT SPRING 10.67x8
1060123019
7257PS,G8 CLINCHER PT REV
1060125837
1 Item Numbers and Part Numbers are subject to change without notice.
Table 17 – Watkiss P2T 2-Knife Trimmer Suggested Spare Parts
Item
Item Number
1
2-Knife Trimmer Care Pack
7603BD38AA
Blade & Anvil Set, 2-Knife Trimmer for BLM500
7603BD39AA
Note: Parts in the 2-Knife Trimmer Care Pack are included in Table 18 below.
Table 18 – Watkiss P2T 2-Knife Trimmer Care Pack contents
Description
Pack size
POWER REG, XP ECG100US28 SMPS 28V 3.6A
1
SWITCH, COMPACT OPTO, 500mm REFLECTIVE
1
FUSE, 1.25",7.0a, HRC-QUICK ACTING, F
10
FUSE, 20mm. 5.0A. GLASS-SLOW EBC, T
10
FUSE, 20mm 250mA GLASS QUICK ACTING, F
10
MOTOR,STEPPER - 57SQx76mm 1.8' 2004
1
PCB ASSEMBLY, STEPPER MTR INTERCONNECT
1
PCB ASSEMBLY, P2T STEPPER MTR CONTEOL
1
PCB ASSEMBLY, (P2T) MAIN CONTROL
1
PCB ASSY, P2T SWITCH PANEL
1
PCB ASSEMBLY, P2T DISCONNECT
1
PCB ASSEMBLY, P2T INTERLOCK
1
ELECT ASSY, PROXIMITY SWITCH 200mm
1
SERVICE AID, USB 2.0A-MiniB CABLE 1.8M
1
BLM550+ Booklet Maker Service Support Guide March 2015
Revision 1 Page 15
