1 Strap mounts
Insert the end of the SS-1200 Shoulder Strap from
the top of the strap mount and pull it from the
exhaust ventilation outlet to attach it to the
camera.
2 Exhaust ventilation outlet (A 39)
3 ONE-SHOT AF (focus automatically once) button
(A 72)/
Assignable button Camera 10 (A 105)
4 Card slots and (A 32)
5 Card compartment cover (A 32)
6 TIME CODE terminal (A 85)
7 Tripod screw holes (1/4"-20, 8.9 mm (0.35 in.)
deep)
8 Speaker (A 122)
