1 REC (start/stop recording) button (A 41)
2Grip belt
Adjust the grip belt so that you can reach the REC
button with your index finger but still have a
comfortable but secure grip.
3 Front control dial (A 59, 62)
4 RF lens mount index (A 26)
5 Built-in microphone (A 89)
6 Power indicator (green)/Tally lamp (red) (A 41)
7 Lens lock pin
8 Lens release button (A 26)
9 Assignable button Camera 11 (A 105)
10 Lens contacts (A 26)
11 AF LOCK button (A 74)/
Assignable button Camera 12 (A 105)
