Canon i960 - Page 34

3 - 5
JASFS2 (ASF Motor [Sheet Feeder Unit])
No. Signal name Function Input/Output
1 ASFA ASF motor phase A+ Out
2 ASFB ASF motor phase B+ Out
3 ASFA- ASF motor phase A- Out
4 ASFB- ASF motor phase B- Out
JPGS1 (Purge Sensor [Purge Unit])
No. Signal name Function Input/Output
1 VSEN_5V Sensor power supply 5V Out
2 GND GND -
3 SNS_PG Purge sensor signal In
JTGUDS1 (CD-R Tray Guide SW [Platen Unit]) *1
No. Signal name Function Input/Output
1 GND GND -
2 CDR_TRY_SW CD-R tray guide sensor signal In
*1: CD-R printing supporting model (i965 only)
J755 （(Paper Feed Cassette <Option>)
No. Signal name Function Input/Output
1 GND Paper feed cassette GND -
2 +27V_AP Paper feed cassette motor drive power supply +27_AP Out
3 VM_CONT Paper feed cassette motor drive power supply control signal Out
4 SNS_U_TURN_UNIT Paper feed cassette sensor signal In
5 STROBE Paper feed cassette strobe signal Out
6 CLK Paper feed cassette data transmission clock signal Out
7 DATA Paper feed cassette data signal Out
8 SLEEP Paper feed cassette sleep signal Out
