4.
Removing the SADF Separation Pad
■ Preparation
1. “Removing the Cartridge” on page 77
2. “ Removing the Left Cover” on page 80
3. “Removing the SADF Unit + Reader Unit” on page 126
4. “Separating the SADF Unit + Reader Unit” on page 129
5. “Removing the SADF Upper Cover Unit” on page 131
■ Procedure
CAUTION:
Do not touch the surface of the roller/pad with bare hands, as doing so will attach skin oil on it and decrease feedability.
1.
4. Parts Replacement and Cleaning
143
