6. If paper dust has accumulated in the Vacuum holes (a) on the Platen or in the Borderless Printing Ink Grooves (b),

use the Cleaning Brush (c), provided with the printer, to wipe it away.

Note

• If the Cleaning Brush is dirty, rinse it in water.

7. Using a damp cloth that you have wrung out completely, wipe inside the Top Cover to clean it. Wipe away any ink

residue on the Platen as a whole, on the Paper Retainer, Borderless Printing Ink Grooves, and blue Switch.

Maintenance and Consumables

Cleaning the Printer

Cleaning Inside the Top Cover iPF6300S

1000
