Removing the Roll from the Printer
See the following procedure for instructions on removing the Roll Holder from the roll.•
(→"Removing the Roll Holder from Rolls," User Manual)
1
2
3
4
5
6
Remove the roll from the Roll 2 (Lower) position (iPF825 only)
Press the Load/Eject button.
Press ▲ or ▼ to select Remove Roll , and then press the
OK button.
Press ▲ or ▼ to select Roll 2 (Lower) , and then press
the OK button.
After confi rming that the Online lamp is off, hold the Roll
Unit Lever (a) and pull out the Roll Unit .
Using both hands, rotate the Roll Holder in the direction
of the arrow to rewind the roll.
Remove the Roll Holder from the Roll Holder Slot .
The roll can now be removed.
a
