28
Replacing Ink Tanks
Store the Ink Tank you removed in the box with the ink holes (a)
facing up. Otherwise, ink may leak and cause stains.
•
Push the Ink Tank Lock Lever down until it locks.•
Make sure the Ink Tank Lock Lever does not return to the original position.•
3
2
Hold the Ink Tank by the grips (a) or handle (b) and
remove it. Press the OK button.
700 ml tanks
330 ml tanks
Lift the stopper (a) of the Ink Tank Lock Lever for the
color to replace. Lift the Ink Tank Lock Lever until it
stops, and then push it down to the front.
330 ml tanks
700 ml tanks
A
A
MBK
BK
GY
Y
M
a
BK
A
A
M
B
K
GY
Y
M
b
A
A
A
A
G
G
B
B
B
a
