7
4
Shake each ink tank gently 7 or 8 times
before opening its pouch.
Important
• Failure to shake the ink tanks may result
in reduced print quality because ink
ingredients have settled on the bottom
of the tank.
Note
• If the ink tank is cold, allow it to adjust to
room temperature before attaching it to
the printer.
5
Open the pouch and remove the ink tank.
A
B
Important
• Never touch the ink holes (A)
or metal contacts (B). Touching
these parts may cause stains,
damage the ink tank, and
affect print quality.
• Avoid dropping the ink tank
after removing it from the
pouch. Otherwise, ink may
leak and cause stains.
• Do not remove ink tanks to shake them
after they have been mounted. Doing so
may cause ink to spill.
6
Mount the ink tank in the holder. Install
with the ink holes facing down and the
metal contacts facing away from you.
Important
• An ink tank cannot be mounted in the
holder if it is not oriented correctly for the
color.
• Do not try to force an ink tank into the
holder if it does not go in normally.
Check the color indicated on the label
and the ink tank orientation, and then try
mounting the tank into the holder again.
1
Instructions on ink tank installation are shown on the screen. Open
the ink tank covers as instructed.
2
Release the ink tank lock lever for the color of ink to install.
Pull the handle part (A) towards you while pressing the button at
position (B).
A
B
Install the 5 ink tanks by following the instructions on the screen.
Install the Ink Tanks
3
Pull out the ink tank lock lever.
Pull straight up. Pull towards you. Securely lay down at a position where
it does not return when you release
your hand.
Important
• Make sure the ink tank lock lever stays in the locked position.
To Next Page
