3-1
imagePROGRAF HDI Driver Guide
Setting Up a Print Job
Chapter 3 Setting Up a Print Job
This section describes the HDI driver settings.
The HDI driver settings are done in the Plotter Configuration Editor dialog box.
Opening the Plotter Configuration Editor Dialog Box
You can open the Plotter Configuration Editor dialog box from either the AutoCAD File menu
or with the Windows Start menu.
■ Opening from the AutoCAD File Menu
1. Select Plot from the AutoCAD File menu.
The Plot dialog box opens.
2. Check the Name setting under Plotter configuration and confirm that W6400PG (the name
of the printer you use) is displayed for the name of the printer to be used.
3. Click the Properties button.
The Plotter Configuration Editor dialog box opens.
■ Opening from the Start Menu
1. Click the Start button then select Settings > Control Panel.
The Control Panel window opens.
To Next Page
