Canon iP2780 - Printer Parts List

(22/23)
3-4. Parts List
Key Part Number Rank Qty Description Remarks
1 QC3-2776-000 J 1 COVER, ASF
2 QM3-6638-000 S 1 ACCESS COVER UNIT iP2700
2 QM3-7343-000 S 1 ACCESS COVER UNIT iP2770
2 QM3-7344-000 S 1 ACCESS COVER UNIT iP2780
2 QM3-7346-000 S 1 ACCESS COVER UNIT iP2772
2 QM3-7347-000 S 1 ACCESS COVER UNIT iP2702
3 QC3-0010-000 J 1 EMBLEM For Japan
3 QC3-0015-000 J 1 EMBLEM For other regions
4 QM3-6636-000 J 1 MAIN CASE UNIT
5 QC3-2781-000 S 1 BASE, KEY
6 QC3-2782-000 S 1 GUIDE, LIGHT
7 QM3-6640-000 I 1 LOGIC BOARD ASS'Y
8 QM3-7225-000 S 1 DC HARNESS ASS'Y
9 QK1-6508-000 I 1 AC ADAPTER: 100/240V 50/60HZ
9 QK1-6521-000 I 1 AC ADAPTER: 100/240V 50/60HZ CN
10 QM3-6639-000 S 1 PRESSING PLATE ASS'Y
11 QS4-2150-000 S 1 SPRING, COMPRESSION
12 QC3-3935-000 I 1 FILM, TIMING SLIT STRIP
13 QC2-8188-000 S 1 SPRING, TIMING SLIT STRIP FILM
14 QM3-6642-000 I 1 CARRIAGE UNIT
15 QC2-8300-000 S 1 COVER, CAP-BLADE B
16 QC2-8296-000 S 1 LEVER, BLADE TRIGGER
17 QC2-8315-000 S 1 COVER, CAP-BLADE F
18 QC2-8297-000 S 1 SPRING, BLADE TRIGGER LEVER
19 QM3-4019-000 S 1 CAP-BLADE UNIT
20 QC2-8289-000 S 1 SPRING, CAP SLIDER
21 QC2-8317-000 S 1 JOINT, TUBE
22 QM3-6367-000 S 1 DRIVE ASS'Y
23 QM3-4014-000 S 1 PICK UP ROLLER ASS'Y
24 QC3-2786-000 S 1 COVER, LF MOTOR
25 QC2-6384-000 S 1 FILM, TIMING SLIT DISK
26 QL2-3285-000 S 1 FEED ROLLER ASS'Y
27 QC3-4534-000 S 1 PLATEN
28 QC2-8244-000 S 1 ABSORBER, PLATEN
29 QL2-3283-000 S 1 EJECT ROLLER ASS'Y
30 QC2-8228-000 S 1 GEAR, LF IDLE
31 QY5-0287-000 S 1 ABSORBER KIT
QH2-2716-000 V 1 CORD, POWER 220V-240V (EUM, EMB, ASA, MY)
QH2-2719-000 V 1 CORD, POWER 100V-120V
QH2-2721-000 V 1 CORD, POWER 220V-240V (KR)
QK1-0776-000 V 1 CORD, POWER 220V-240V (AU)
QK1-1355-000 V 1 CORD, POWER 220V-240V (BR)
QK1-1675-000 V 1 CORD, POWER 220V-240V (GB, HK)
QK1-2017-000 V 1 CORD, POWER 100V-120V (TW)
QK1-3048-000 V 1 CORD, POWER 120V-240V (LAM, CHN)
QK1-3761-000 V 1 CORD, POWER 100V (JP)
S1 XA9-1807-000 G SCREW, TP M3x8
