CHAPTER 2 STANDARDS AND ADJUSTMENTS
2-14
6) Lead the longer end [14] along the cable drive pulley [1], and hook it on the pulley [15] on the
right front side.
Figure 2-24
7) Lead the longer end [14] under the No. 1 mirror mount [8] and the No. 2/3 mirror mount [9];
then, hook it on the pulley [16] on the left front side and the pulley [17] of the No. 2/3 mirror
mount.
Figure 2-25
[14]
[15]
[1]
[8]
[17]
[9]
[16]
[14]
